SBW SF85 – BIFOLD
Geometry system
- Sash Width: 85 mm
- Glazing: 20-53mm, 34-75mm (structural)
- Locking: 5-point (door), 4-point (intermediate sashes)
- Visible Aluminium: 86mm urban & minimal / 105mm standard
- Maximum Weight: 200Kg/ vent
Thermal performance
-
Uw =1.0 W/m²K
Maximum Glass Thickness
- 20-53mm, 34-75mm (structural)
Acoustic Performance
Interested in our products?
- Request an offer now!
Description
A world-class highly insulated folding door system with bottom-slide operation, which combines minimal aesthetics with outstanding performance, very large dimensions with literally low sight lines, enhanced burglar protection with a very large variety of solutions.
Advantages:
- Very large dimension in terms of height (up to 4.0m), vent width (up to 1.5m)and total span width
- Amazingly reduced sight lines which contributes to the overall minimal design
- Complete range of technical solutions & typologies (odd & even number of vents, corner construction, inwards or outwards, thresholds).
- Wide selection of vents for different aesthetic outcomes (standard, minimal, steel-look, semi-structural).
- Extreme performance in terms of air permeability, wind load resistance and water tightness
- Significant energy and cost saving due to the excellent thermal insulation and U-values (as low as 1.0 W/m2K)
- Enhanced levels of security and burglar protection, meeting all sector security standards
- Smooth operation and long-lasting flawless functionality
Typologies:
Odd number of vents on one side
Odd number of vents plus door
Odd number of vents on both sides (meeting stile)
Odd number of vents on one side
Corner construction with single door
Corner construction with odd number of vents on both sides
Odd number of vents on both sides (meeting stile)
Even number of vents on one side
Even number of vents plus door
Even & odd number of vents on both sides (meeting stile)
Even number of vents on both sides (meeting stile)
GENERIC:
THERMAL INSULATION:
- Yes
AESTHETICS:
- minimal, relatively low sight line
OPERATION:
- bottom slide
PANEL:
- standard, minimal, steel-look, semi-structural
APPLICATIONS:
- luxurious residences, commercial facilities
TECHNICAL CHARACTERISTICS:
SASH WIDTH:
- 85 mm
GLAZING:
- 20-53mm, 34-75mm (structural)
POLYAMIDE:
- Double 40mm
EXTRA INSULATING FITTINGS:
- Alumil energy bar insulation and PE insulation foam
MAIN GASKET:
- Unified co-extruded EPDM/ foam
LOCKING:
- 5-point (door), 4-point (intermediate sashes)
VISIBLE ALUMINIUM:
- 86mm urban & minimal / 105mm standard
MAXIMUM WEIGHT:
- 200Kg/ vent
MAXIMUM HEIGHT
- 4,0 m
MAXIMUM PANEL WIDTH
- 1,5 m
PERFORMANCE:
WATER TIGHTNESS
- 7A/9Α (with subsill)
AIR PERMEABILITY
- class 4
WIND LOAD RESISTANCE
- class C3/B3
BURGLAR RESISTANCE
- RC2 IFT & PAS24 (UK)
Characteristics
- THERMAL PERFORMANCE: 1.0 W/m²K
